Grundfos DMH 19-10D AR-PPL/V/C-R-G1U2U2FEMAG (99822153)
Produkt ID: 99822153
Prijsaanvraag en beschikbaarheid
Grundfos DMH 19-10D AR-PPL/V/C-R-G1U2U2FEMAG (99822153)
Grundfos DMH 19-10D AR-PPL/V/C-R-G1U2U2FEMAG (99822153)
| Regeling: | |
| Type aansluiting: | Type E/F (CEE7/7) |
| Type of controlevariant: | AR Electronic |
| Frequency converter: | Niet voorbereid voor frequentie omvormer |
| Vloeistof: | |
| Te verpompen medium: | Water |
| Bereik vloeistoftemperatuur: | 0 .. 40 °C |
| Medium temperatuur tijdens bedrijf: | 20 °C |
| Dichtheid: | 998.2 kg/m³ |
| Technisch: | |
| Nominaal debiet bij 50 Hz: | 19 l/h |
| Aantal doseerkoppen: | 2 |
| Goedkeuringen: | CE,EAC,CNROHSEX |
| Type terugslagklep, inlaatpomp 1: | Standard |
| Type terugslagklep, uitlaatpomp 1: | Standard |
| Max viscositeit: | 100 mPas |
| Materialen: | |
| Pomphuis: | Aluminium |
| Doseerkop, pomp 1: | Plastic |
| PP | |
| Doseerkop, pomp 2: | Plastic |
| PP | |
| Materiaal kogel: | Ceramic |
| Klep kogel: | Al2O3 |
| Klepzitting: | Rubber |
| Klep zitting: | FKM |
| Afdichting: | FKM |
| Rubber | |
| Installatie: | |
| Max. Werkdruk bij 50 Hz: | 10 bar |
| Maximaal toelaatbare voordruk: | 8 bar |
| Type zuig aansluiting: | Connection pack |
| Type persaansluiting: | Connection pack |
| Maat van de zuigaansluiting: | 4/6, 6/9, 6/12, 9/12 |
| Maat van de persaansluiting: | 4/6, 6/9, 6/12, 9/12 |
| Elektrische gegevens: | |
| Vermogen P1: | 0.09 kW |
| Netfrequentie: | 50 Hz |
| Max. frequentie: | 50 Hz |
| Nominale spanning: | 1 x 220/240 V |
| Dichtheidsklasse (IEC 34-5): | IP65 |
| Kabel inbegrepen (ja/nee): | J |
| Stekker: | Schuko plug |
| Overige: | |
| Netto gewicht: | 15 kg |
| Bruto gewicht: | 26.3 kg |
| Transportvolume: | 0.156 m³ |
| Membraan Lekdetectie: | Y |
Applicaties
- Industrial process water treatment — Our advanced pumping solutions are more intelligent, more capable and more reliable, with autonomous, data-driven technology that connects and optimizes your entire system ultimately saving you time, money and maintenance.
- Koeling — Industriële toepassingen, zoals bewerkingsprocessen en verwarmingssystemen, zijn afhankelijk van een efficiënte warmteoverdracht. Grundfos levert efficiënte, betrouwbare pompen en systemen voor een breed scala aan koeltoepassingen en voor OEM-koelunits.
- Process liquids transfer — A wide range of pumps for the transfer of water, cooling lubricants and other liquids in industrial and process systems.
categorie
- Mechanische doseerpompenKrijg een compleet overzicht van de robuuste, membraangebaseerde mechanische doseerpompen van Grundfos voor veeleisende waterbehandeling en industriële toepassingen.
