Grundfos CR 1-2 A-B-A-E-HUBE
Produkt ID: 96510221
Prijsaanvraag en beschikbaarheid
Grundfos CR 1-2 A-B-A-E-HUBE
Grundfos CR 1-2 A-B-A-E-HUBE
| Vloeistof: | |
| Te verpompen medium: | Water |
| Bereik vloeistoftemperatuur: | 0 .. 120 °C |
| Medium temperatuur tijdens bedrijf: | 20 °C |
| Dichtheid: | 998.2 kg/m³ |
| Technisch: | |
| Toerental waarop de pompgegevens zijn gebaseerd: | 3447 omw/min |
| Nominaal debiet: | 2.2 m³/u |
| Nominale opvoerhoogte: | 14.7 m |
| Plaatsing: | Verticaal |
| Asafdichting arrangement: | Enkel |
| Primaire asafdichting: | HUBE |
| Code voor asafdichting: | HUBE |
| Curve tolerantie: | ISO9906:2012 3B |
| Materialen: | |
| Pomphuis: | Gietijzer |
| EN 1561 EN-GJL-200 | |
| ASTM A48-25B | |
| Waaier: | Roestvast staal |
| EN 1.4301 | |
| AISI 304 | |
| Installatie: | |
| Maximale bedrijfsdruk: | 16 bar |
| Max. druk bij toegestane temp: | 16 bar / 120 °C |
| 16 bar / 0 °C | |
| Type aansluiting: | Oval / NPT(F) |
| Maat van de zuigaansluiting: | 1 inch |
| Maat van de persaansluiting: | 1 inch |
| Druktrap voor leidingaansluiting: | PN 16 |
| Flensmaat van de motor: | FT85 |
| Elektrische gegevens: | |
| Motor standaard: | IEC |
| Vermogen (P2) benodigd voor pomp: | 0.37 kW |
| Regeling: | |
| Frequency converter: | NONE |
| Druksensor: | N |
| Overige: | |
| Netto gewicht: | 18 kg |
| Bruto gewicht: | 20.7 kg |
| Transportvolume: | 0.054 m³ |
