Grundfos CR 1-4 A-FGJ-A-K-HQQK
Produkt ID: 96867664
Prijsaanvraag en beschikbaarheid
Grundfos CR 1-4 A-FGJ-A-K-HQQK
Grundfos CR 1-4 A-FGJ-A-K-HQQK
| Vloeistof: | |
| Bereik vloeistoftemperatuur: | 0 .. 120 °C |
| Technisch: | |
| Toerental waarop de pompgegevens zijn gebaseerd: | 3485 omw/min |
| Nominaal debiet: | 2.2 m³/u |
| Nominale opvoerhoogte: | 27.2 m |
| Plaatsing: | Verticaal |
| Asafdichting arrangement: | Enkel |
| Primaire asafdichting: | HQQK |
| Code voor asafdichting: | HQQK |
| Goedkeuringen: | CE |
| Curve tolerantie: | ISO9906:2012 3B |
| Materialen: | |
| Pomphuis: | Gietijzer |
| EN 1561 EN-GJL-200 | |
| ASTM A48-25B | |
| Waaier: | Roestvast staal |
| EN 1.4301 | |
| AISI 304 | |
| Installatie: | |
| Maximale bedrijfsdruk: | 25 bar |
| Max. druk bij toegestane temp: | 25 bar / 120 °C |
| 25 bar / 0 °C | |
| Type aansluiting: | DIN / ANSI / JIS |
| Maat van de zuigaansluiting: | DN 25/32 |
| 1 1/4 inch | |
| Maat van de persaansluiting: | DN 25/32 |
| 1 1/4 inch | |
| Druktrap voor leidingaansluiting: | PN 25 |
| Druktrap van de zuigaansluiting: | 250 lb |
| Flensmaat van de motor: | 56C |
| Elektrische gegevens: | |
| Motor standaard: | NEMA |
| Regeling: | |
| Frequency converter: | NONE |
| Druksensor: | N |
| Overige: | |
| Netto gewicht: | 18.5 kg |
| Bruto gewicht: | 23.5 kg |
| Transportvolume: | 0.14 m³ |
