Lowara CO COF CEF Centrifugal Pump with open impeller

Specifications

Flow

Head

Range

Operating pressure

Ambient temperature

Liquid temperature

Power supply

Insulation class

Enclosure class

max 54 m³/h (900 l/min)

max 24 m

0,37 - 3 kW (0,5 - 4 HP)

8 bar

0° - 40° C

-10° - +120° C

1~ 220 - 240V , 3~ 230 - 400V

F (155° C)

IP55

Materials

Pump body

Impeller

Elastomers

Mechanical seals

Stainless Steel AISI 316L

Stainless Steel AISI 316L

FPM

Ceramic-Carbon

Identification

COM350/15

CO

M

350

/15

/D

-

serial name

M = singel-phase, T = three-phase

nominal flow l/min

rated motor power (kW x 10)

pump fits IE3 motor three fase only
