Lowara LNE, LNEE, LNES single-impeller centrifugal pump

Specifications LNEE

Flow

Head

Range

Operating pressure

Ambient temperature

Liquid temperature

Power supply

Insulation class

Enclosure class

max 305 m³/h

max 95 m

0,25 - 22 kW (0.4 - 30 HP)

16 bar

0° - 40° C

-25° - +120° C

1~ 220 - 240V, 3~ 230 - 400V

F (155° C)

IP55

Specifications LNEEH with Hyrdrovar

Flow

Head

Range

Operating pressure

Ambient temperature

Liquid temperature

Power supply

Insulation class

Enclosure class

max 305 m³/h

max 95 m

0,25 - 22 kW (0.4 - 30 HP)

16 bar

0° - 40° C

-25° - +120° C

3~ 230 - 415V to 3kW, over 380 - 690V

F (155° C)

IP55

Specifications LNES

Flow

Head

Range

Operating pressure

Ambient temperature

Liquid temperature

Power supply

Insulation class

Enclosure class

max 410 m³/h

max 263 m

0,55 - 37 kW (0.75 - 50 HP)

16 bar

0° - 40° C

-25° - +120° C

3~ 230 - 415V to 3kW, over 380 - 690V

F (155° C)

IP55

Specifications LNESH with Hydrovar

Flow

Head

Range

Operating pressure

Ambient temperature

Liquid temperature

Power supply

Insulation class

Enclosure class

Materials

Pump body

Impeller

Elastomers

Mechanical seals

Cast iron

Stainless Steel or Cast iron

EPDM

Silicon Carbide-Carbon

Identification

LNEE 50-125/40/P25VCS4

LNE

50

125

40

P2

5V

C54

C

S

4

-

serial name

discharge port DN 50

nominal impeller diameter

40 kW rated motor power (kW x 10) 4 x 10 = 40

motor type P 2 = 2 poles,  4 = 4 poles

frequency 5 = 50Hz,  V = 3 x 380 -415V/6

Casing, impeller,mech-seal material

Casing material C = Cast iron

impeller material C = Cast iron, S = fabricated

mech-seal material, see type of seal
