Lowara SHO, SHOS, SHOD single stage centrifugal pump, open impeller

Specifications

Flow

Head

Range

Operating pressure

Ambient temperature

Liquid temperature

Power supply

Insulation class

Enclosure class

max 56 m³/h (900 l/min)

max 50 m

0,37 - 11 kW (0,5 - 15 HP)

12 bar

0° - 40° C

-10° - +120° C

3~ 230 - 400V to 3kW, over 400/690V

F (155° C)

IP55

Materials

Pump body

Impeller

Elastomers

Mechanical seals

Stainless Steel AISI 316

Stainless Steel AISI 316

FPM

Silicon carbide-slicon carbide

Identification

SHOE25-125/22/D

SHO

E

25

125

22

/D

-

serial name

E = close coupled version, null = 2 poles, 4 = 4 poles

discharge port nominal diameter

size of the pump

rated motor power (kW x 10)

pump fits IE3 motor three fase only
