Lowara ESHE, ESHS, ESHF, horizontal centrifugal pumps

Specifications ESHE

Flow

Head

Range

Operating pressure

Ambient temperature

Liquid temperature

Power supply

Insulation class

Enclosure class

max 222 m³/h

max 50 m

0,75 - 22 kW (1 - 30 HP)

12 bar

0° - 40° C

-10° - +120° C

1~ 220 - 240V , 3~ 230 - 400V

F (155° C)

IP55

Specifications ESHS

Flow

Head

Range

Operating pressure

Ambient temperature

Liquid temperature

Power supply

Insulation class

Enclosure class

max 240 m³/h

max 110 m

0,75 - 37 kW (1 - 50 HP)

12 bar

0° - 40° C

-10° - +120° C

3~ 230 - 400V to 3kW , over 400/690V

F (155° C)

IP55

Specifications ESHF  Frame mounted

Flow

Head

Range

Operating pressure

Ambient temperature

Liquid temperature

Power supply

Insulation class

Enclosure class

max 240 m³/h

max 110 m

0,75 - 37 kW (1 - 50 HP)

12 bar

0° - 40° C

-10° - +120° C

3~ 230 - 400V to 3kW , over 400/690V

F (155° C)

IP55

Materials

Pump body

Impeller

Elastomers

Mechanical seals

Stainless Steel AISI 316

Stainless Steel AISI 316

FPM

Ceramic-Carbon

Identification

ESHE40-160/55/P25VSNA

ESHE

40

160

55

P2

SV

SNA

-

serial name

discharge port DN40

size of the pump

55 kW rated motor power (kW x 10) 5,5x10=55

motor type P, 2=2 poles 4=4 poles

frequency S=50Hz, voltage  V=3x380-415/6

material type for casing S impeller N mec
